Problem Solvers Sheldon Fender Nuts - 10 & 32 mm - Per Pair

Customer Reviews (3)

5 / 5| Write your review

£17.99

was

View supersize image

£17.99 was

Manufacturer :

SJS Cycles part number :

Manufacturer part number :

Details

The Problem Solvers Sheldon Fender Nut was designed to replace the standard brake nut and allow convenient fender (mudguard) mounting on steel and aluminium road frames and forks.

Product Uses:

Essentially, this is a long brake nut for road forks, as it allows the road brake nut to thread into it for brake mounting. But, it also has threading inside so that a fender (mudguard) mounting bolt can be threaded into the back of the fork. Sheldon Fender Nuts are supplied as a pair: 32mm length for front fork crowns, 10mm length for rear bridge.The fender nut will work with all steel and aluminum frames and forks; it also will work with some carbon forks, but check first. It will not work with forks requiring an extended brake nut or a narrow brake nut (such as Reynolds). Technical details: PS Sheldon Fender Nut is a standard 6mm brake nut with longer internal threading and an extension on the back side for a 6mm mounting bolt
Simply install your brake as you would normally then with a 6mm bolt (not supplied), mount the fender (Mudguard) to the back side of the nut and to your fork or frame

Related products

Gilles Berthoud Brake Spindle Screw for Mudguards £6.99 Inc VAT Quick view

Product Reviews (3)

Overall Product Rating 5 / 5

Useful for fixing mudguards on bikes with tight clearances

By Matthew

21 Jun 2022

5 / 5

I recommend this product

ProsAdds more convenient mudguard fixings to bikes without them

I have a couple of bikes with tight clearances for mudguards and these are very useful. By moving the bracket from the brake bolt to the rear of the fork or brake bridge, this gets the fixing out from under the arch and improves clearance. Also makes it easier to remove guards in summer if you want to, as you don't need to remove the brakes. The long front bolt can easily be cut to length with a hacksaw. You'll need M6 bolts to fix your mudguards.

Fast delivery

By marcouxclaude

02 Mar 2021

5 / 5

I recommend this product

did not tried but seems excellent

Sheldon Fender Nuts

By Ray smith

13 Jan 2017

5 / 5

I recommend this product

Consexpensive. no bolts

Prosextra clearance. Leave brakes in situ if removing guards

The selling point for these seems to be that you can fit brakes and guards independently which you can. As these are for my winter bike that didn't attract me as I leave the guards on all year. However what they did is give more clearance because the bracket is no longer under the forks. This extra clearance has stopped guards getting clogged with mud which is exactly why I bought them. I think they're expensive for what they are and should come with the bolts for the guards but would buy them again

Questions & Answers (5)

Can you recommend which specific bolt I need to buy, to attach to the end?

By Tom H

08 Oct 2021

(Planning to attach a steering stabiliser to my recessed brake nut)

SJS Customer Service:

An M6 bolt is needed- we cannot be specific as you may want a button or socket head depending on the clearance.

JK 11.10.21

For the front 13mm is too short, but 32mm too long. Is it ok to cut the 32mm down to size?

By Andrew

20 Sep 2019

SJS Customer Service:

Yes you could cut these to size.

Thanks - 24/09/19

Trek Domane

By trevor

03 Jun 2018

Hi my recessd nut which i use with ultegra brakes in carbon fork is 28mm will these bolts work?

SJS Customer Service:

Hi there,

Yes the 32mm version should work.

Thanks

Is the head the same outer diameter as a recessed nut?

By Ian

18 Jan 2018

I have carbon forks with a recessed brake nut. For the Sheldon Fender nut to work, it would have to sit inside the fork.

Does the outer diameter of the head allow this?

Thanks

SJS Customer Service:

Hi there,

Yes it should sit snug into the back of the fork.

Thanks

For The Front 32Mm Can You Please Tell Me The Head And Shank Lengths Thanks

By Dave A

29 Apr 2017

SJS Customer Service:

Hi,

The shaft length is the 32mm and the head is an additional 10.5mm.

Thanks.
