Chater-Lea Grand Tour 1x Single Crankset - Clear w/ PVD Fixings - 36T - 170mm

£520.00
was
£520.00 Please note this product has selling restrictions to your country. was
Manufacturer :
SJS Cycles part number :
Manufacturer part number :
Details
The latest addition to Chater-Lea's Grand Tour range, the Grand Tour Single cranksets are designed to be both beautiful and resilient, perfect for road or cross 1x use. Every component including crank arms, chainrings and fixings are proudly made in Britain using the finest materials, including 7050 and 7075 grade aluminium and 316 stainless steel. Machined using the latest CNC technology, with the 'grain' of the material aligned for maximum strength. The finish on the dust caps and chainring bolts are PVD-coated for an authentic brass accent and signature look (also available in raw steel finish). All Chater-Lea's cranksets are anodised to enhance protection. The Grand Tour Single cranksets are available in 40T or 36T options.

Dimensions:
- Crank Arms: 170mm
- Chainrings: 36T (156.06mm)
- Compatibile with 9, 10 or 11 speed chains
- Q Factor: 142mm
- Requires JIS square taper bottom bracket with 110mm spindle length
- Total Weight: 565g

Materials:
- Anodised aluminium 7050 T7451 (crank arms)
- Anodised aluminium 7075 T6 (chainrings)
- 316 Stainless steel (nuts, bolts and dust caps)

Finish:
- Machined aluminium (crank arms and chainrings)
- Machined steel (nuts, bolts and dust caps in PVD-coated finish)

PVD-Coating:
Physical Vapour Deposition (PVD) is a process utilising powerful magnetic fields to apply an extremely uniform and ultra thin coating to a component. Chater-Lea's PVD coating is a super hard, corrosion resistant layer of Titanium Nitride around 2 microns thick. The PVD process vaporises the Titanium Nitride allowing it to be electrically applied to the component with extreme adhesion. It is in fact nearly as hard as sapphire, itself second only to diamond in hardness.
