26 inch Thorn Nomad Mk3 Steel Fork - Gunmetal Imron

£179.00
was
Offset
£179.00 Please note this product has selling restrictions to your country. was
Manufacturer :
SJS Cycles part number :
Manufacturer part number :
Details
- For rim brake use only
- High quality Reynold steel blades and Cr-Mo steerer
- Thorn Twin Plate Crown is lightweight, very strong and gives more clearance compared to various other unicrown designs
- Reversible brake bosses allow either 26" (559) or 650b (584) rims
- For use with cantilever or V-brakes
- Stainless steel fittings for direct and secure mounting of mudguards
- M6 Stainless fittings for mudguards stays and lo-loader front carrier
- Steerer: 1 1/8 inch
- L1 Dimension (Axle to Crown Race Seat): 410mm
- NOTE: Does not include crown race seat

Sufficient clearance for use with mudguards and 26" tyres up to 2.35" or 650b tyres up to 60b.

Available in three different offsets to suit the corresponding Thorn Nomad Mk3 frames.

A = 48mm - suitable for: 55L, 58L, 61S, 61L
B = 53mm - suitable for: 47S/T, 50L, 52L, 58S
C = 60mm - suitable for: 40S/T, 50S, 52S, 55S
Product Reviews (0)
Questions & Answers (5) Q & A
Specification
Downloads
Download File
Be the first to write a review
Feel free to leave a review of this product, good or bad it helps other customers with their buying decision.
Questions & Answers (5)
What is the max tyre clearance of this fork?
By
09 Jun 2022
As per the description: Sufficient clearance for use with mudguards and 26in tyres up to 2.35in Were you not to use mudguards and not to be bothered about enough clearance to stop mud clogging or wearing off paint as the wheel flexes under load you'd get 2.5in tyres in. RT 10/06/2022
Are the offsets the size of the stem height?
By
08 Jun 2022
I'm looking to purchase this fork for a different bike, what does the offset mean?
Imagine a straight line through the centre of the steerer tube, also a straight line through the centre of the front hub (at 90 degrees) the offset is how far in front of the steerer line the hub axle line is. RT 10/06/2022
Could you tell me whether the brake posts and fittings are tig-welded or brazed on?
By
08 Mar 2021
Thank you for your enquiry, they are very neat TIG welded

WD 10/03/21
Weight and bosses
By
08 Dec 2020
What is the weight of this fork?
Are the reversible bosses included?
The Approx weight of this fork is 1385g- reversible bosses are not included.

JK 11.12.20
Is it threadless?
By
18 Apr 2020
Hi, yes it is. Thanks 20/04/2020
