Robert Axle Project Lightning Bolt-on Front Axle - M12 x 1.5 - 120mm

Customer Reviews (1)
5 / 5| Write your review
£54.99
was
£54.99 Please note this product has selling restrictions to your country. was
Manufacturer :
SJS Cycles part number :
Manufacturer part number :
Details
Robert Axle Project Lightning Bolt-On Axles offer a low profile & lighter weight alternative to those ugly & bulky thru axle levers on your bike. Replace them with the highest quality thru axles. Available in front & rear sizes.

- Lightning is Better: Available front & rear Lightning Bolt-On axles offer a stronger, more durable, lower profile & lighter weight option to replace your stock thru-axles.
- Low Profile: No more bulky handles to strike trail obstacles. Aerodynamic design.
- Light Weight: RAP axles are internally bored to remove unnecessary material without compromising strength.
- Easy to install: The matching front & rear Lightning Bolt-On Axles only require a standard 6mm hex wrench for easy installation & removal.
- Better Tolerances: Manufactured in the USA to the tightest tolerances using aerospace materials & CNC manufacturing. No longer will your axle loosen while riding.

Dimensions:
- Length: 120mm
- Thread Pitch: M12 x 1.5
- Thread Length: 17mm
- Weight: 28 grams
Product Reviews (1)
Questions & Answers (3) Q & A
Specification
Downloads
Download File
Product Reviews (1)
Overall Product Rating 5 / 5
A good replacement for OEM thru axle
By Richard Fotheringham
21 May 2025
5 / 5
I recommend this product
ConsPrice is too high
ProsFitted my bike, seems well made
I bought this for my 2021 Surly Disc Tourer, after the aluminium washers on the original axles disintegrated. I contacted Surly who said they don't sell replacement axles, and these were the only option I could find available in the UK. The price stung, considering it's basically a long M12 bolt, but they've done the job which is pretty much all you can say of an axle. Probably a particular quick of the Surly Disc Tourer dropouts, but I decided to use some nordlock washers on the non-threaded side to make sure they don't slip. This arrangement is working great so far, although I didn't test the axles without these.
Questions & Answers (3)
Ref robertaxleproject
By
04 Feb 2025
Do you have axles in a blue colour.

Many Thanks

Iain Wilson
The axles are only available in black. SK 04/02/25
Cotic Roadrat
By
30 May 2022
Hi, my current through bolt has no spec on it. It is M12 and 1.5 pitch according to the sheet provided. 106mm unthreaded and 13mm threaded, will this bolt be ok? Thanks, Mark
Please email [email protected] so we can best advise.
Can you tell me what the thread length is on this?
By
20 Nov 2020
My current through axle is marked "12.0 *106.0L*M12(P1.5)*14.0L" - which I guess means 12mm diameter, 106mm unthreaded, M12 bolt with 1.5 thread pitch and 14mm thread length (making a total of 120mm length from the axle head). So will this bolt fit as a replacement? Thanks, Mark
This bolt is most likely to be the replacement you need based on your proved specifications. Thread length on this is approx 16mm.

JK 23.11.20
