700c 622 Front Wheel 32h DT Swiss R 470 Disc Rim with Shimano DH-UR705-3D Dynohub - Black

£207.99
was
£207.99 Please note this product has selling restrictions to your country. was
Manufacturer :
SJS Cycles part number :
Manufacturer part number :
Details
Perfect for those looking for a Dynamo wheel for 12mm through axle bikes!

Built using the fantastic Shimano DH-UR705-3D dynamo hub, and this wheel offers great strength, reliability and performance at a great price, featuring the tubeless compatible DT Swiss R 470 DB Rim. Suited for tyres 28-50mm wide!

Approx. Weight: 1160g
Spokes- Disk side : Jtek 14G Black plain gauge spokes- 287mm X 16
Spokes- Drive side: Jtek 14G Black plain gauge spokes- 286mm X 16
Nipples: Jtek Black Brass- 12mm x 2 (Flats measure 3.20mm)
Tyre Width Range: 28-50mm
Rim: DT Swiss R 470 DB 700c (32 Hole, Presta Drilled)
Hub: Shimano DH-UR705-3D
OLN: 12 X 100mm (12mm thru axle)
Disk Rotor Fitting: Shimano Centerlock

NOTE: For tubeless setup DT Swiss valves, tape and tubeless Tyres are recommended for optimum performance and ease of setup (not included).

Hub Spec:
- Highly efficient, super light weight, premium grade 6 volt 3 watt dynamo front hub for easy to use and ridged 12mm axle fitment
- Provides bright illumination for safer night riding without the need and expense of replacing batteries
- Important weight savings are made by using an efficient and light weight aluminium coil structure
- Labyrinth and contact sealing as used on the premium groupsets - low-friction seals and internal grease sleeve effectively shut out water, mud, and dirt without affecting rotational smoothness increasing service life
- Borozon treated cup and cone bearing races - super mirror finish bearing races reduce friction providing smooth and precise bearing rotation
- Push-in wiring harnesses make installation fast and easy
- Double anodized, premium finish forged aluminium hub shell
- 12mm x 100mm O.L.D. (SM-AX720 axle sold separately)
- Average weight 550 grams

Rim Spec:
- Can be run either with standard clinchers or road tubeless tyres using DT Swiss tubeless tape & valves
- Unique process for the black coating produces a tough & durable finish
- Suggested maximum system weight of 120KG.

- Presta drilling
- Outer Width: 24mm
- Inner Width: 20mm
- Height: 23mm
- Weight: 450 grams
